An Arazzo workflow is a document. But a good part of what it says is written inside small strings: $inputs.petId, $steps.find-pet.outputs.petId, $response.body#/id. Each one is a runtime expression, and each one tells a run where to get a value.
So what do we have inside such a string? A small language of its own. It is defined in ABNF in the Runtime Expressions section of the specification, and a YAML loader has no opinion about it. $steps.find-pet.output.petId, with output where the grammar wants outputs, is a perfectly good string. So the typo waits for a run against a live API, and shows up at the step that uses it.
This tutorial is about that small language, using @usearazzo/parser to tackle its complexities. We will parse an expression into a syntax tree. We will tell a valid one from an invalid one, and find where it stops parsing. And we will see where parsing ends and Arazzo document validation begins. The script is under forty lines, and you will have it running in a few minutes.
The end result
Here is where we will end up. Type any runtime expression below. The parser takes it apart into a tree, or shows where it stops making sense.
That is the whole idea in one picture. A runtime expression looks like a string, and to a YAML loader it is one. To the parser it is a small program with parts: what it reads from, which step or input, which field, which pointer into a body. A tool can act on the parts, and it can report where the parsing stopped.
Now let’s build the same thing as a Node script, and then run it over a real document.
The document is adopt-a-pet.arazzo.yaml, an Arazzo 1.1.0 workflow. Download it, along with the petstore.openapi.yaml it names and the finished script, check-expressions.mjs, into a directory of their own.
Two lines in it deserve a look. Line 30 has a JSON Pointer without its slash, and the script will find it. Line 36 holds an expression that is valid and still wrong. The last section is about that one.
arazzo: 1.1.0
info:
title: Pet adoption
version: 1.0.0
sourceDescriptions:
- name: petstore
type: openapi
url: ./petstore.openapi.yaml
workflows:
- workflowId: adopt-a-pet
inputs:
type: object
properties:
petId:
type: string
steps:
- stepId: find-pet
operationId: $sourceDescriptions.petstore.getPetById
parameters:
- name: petId
in: path
value: $inputs.petId
successCriteria:
- condition: $statusCode == 200
- context: $response.body#/status
condition: ^available$
type: regex
outputs:
petId: $response.body#/id
name: $response.body#name
- stepId: adopt
operationId: $sourceDescriptions.petstore.adoptPet
parameters:
- name: petId
in: path
value: $response.body#/id
successCriteria:
- condition: $statusCode == 201
outputs:
adoptionId: $response.body#/id
outputs:
adoptionId: $steps.adopt.outputs.adoptionId
Notice where the runtime expressions sit: the two operationId fields (lines 17 and 32), the two parameter values (21 and 36), the one criterion context (24), and the four outputs (28, 29, 40, and 42). The two condition fields are not runtime expressions. A simple condition is a grammar of its own that has runtime expressions as operands, and a regex condition is a regular expression.
Install the parser
In that directory:
npm install @usearazzo/parser @speclynx/apidom-core
Why two packages? @usearazzo/parser does the parsing. It gives us parseRuntimeExpression for the expressions, which is what this tutorial is about, and parseArazzo for the sample document in the last step. @speclynx/apidom-core gives us toValue. We will need it at the end, to get a plain string out of a node of the parsed document.
Parse one expression
Let’s start with one expression and see what the parser makes of it. parseRuntimeExpression takes the expression and parses it with the grammar from the specification. It is synchronous, and it needs no document. Save this as check-expressions.mjs:
import { parseRuntimeExpression } from '@usearazzo/parser';
const { result, tree } = parseRuntimeExpression('$steps.find-pet.outputs.petId');
console.log(result.success);
console.log(JSON.stringify(tree, null, 2));
Run it:
node check-expressions.mjs
true
{
"type": "StepsExpression",
"stepId": "find-pet",
"field": "outputs",
"outputName": "petId"
}
$steps.find-pet.outputs.petId
- StepsExpression$steps
- stepIdfind-pet
- fieldoutputs
- outputNamepetId
result.successtrue
What have we just done? Well, we turned a string into a syntax tree. Drawn, that object is the tree the playground showed: the expression taken apart into which step, which field, which output.
Notice the root type. It names what the expression reads from. $steps gave us a StepsExpression, and every other prefix has a type of its own: $inputs an InputsExpression, $response a ResponseExpression, $statusCode a StatusCodeExpression, and so on, thirteen in all. The playground is the quickest way to meet the rest. Try $response.body#/id there, and notice how the JSON Pointer on the end becomes a node too, with its reference tokens split out.
The grammar is Arazzo 1.1.0’s. It covers the 1.0.x forms too, with one tightening: a step id, workflow id, or source description name may contain only letters, digits, -, and _.
Tell valid from invalid
So what happens when the expression is wrong? Nothing is thrown. parseRuntimeExpression reports bad syntax through its result: result.success is false, and result.maxMatched is the offset up to which parsing succeeded. Whatever starts there is the part that does not parse, and the offset is an error message on its own: a caret under the spot.
Let’s see it. Replace the script with a check function and three calls, one valid and two typical typos:
import { parseRuntimeExpression } from '@usearazzo/parser';
function check(expression) {
const { result } = parseRuntimeExpression(expression);
if (!result.success) {
console.log(`${expression}\n${' '.repeat(result.maxMatched)}^ does not parse`);
}
}
check('$steps.find-pet.outputs.petId');
check('$steps.find-pet.output.petId');
check('$response.body#name');
$steps.find-pet.output.petId
^ does not parse
$response.body#name
^ does not parse
The valid one printed nothing. The first typo parsed as far as $steps.find-pet, then met .output. where the grammar wants .outputs.. The second parsed $response.body# and then found n, where a JSON Pointer has to start with /.
Notice where the first caret sits. Not under the missing s, but under the dot that starts .output.. Why? Because the grammar reads .outputs. as one piece, and a piece either matches whole or not at all. So the caret marks where the piece that failed begins. When that piece is a single character, as in the second typo, the caret is on the very character.
$steps.find-pet.output.petId
- StepsExpression$steps
- stepIdfind-pet
- not accepted.output.petIdfrom offset 15
invalidparsing stopped at offset 15, where the grammar wants .outputs.result.maxMatched: 15
So there it is: valid or not, and if not, where it stopped.
Run it on a document
Now let’s feed check real expressions from the sample instead of three literals. We also want to say where each problem is in a way you can find: the file, the line, and the column.
This is a demonstration, so the script looks at one kind of field only: the outputs of every step. An output is always a runtime expression, which makes it the simplest place to start. The other places are listed in Next steps.
Give check the element
So far check has been getting strings. But a string does not know where it came from, and we want line numbers. So what does know? The parsed document. parseArazzo reads the file and returns a typed tree, and with sourceMap: true every element in that tree remembers its line and column. One catch: source maps need strict: false, the parser’s tolerant mode.
Replace the import line with these two:
import { parseArazzo, parseRuntimeExpression, ParseError } from '@usearazzo/parser';
import { toValue } from '@speclynx/apidom-core';
Now let’s hand check an element of that tree instead of a string. It gets the value out with toValue, and puts the element’s position in front of each problem. Notice the two + 1. startLine and startCharacter count from zero, and people count from one. Replace check and the three calls with:
const file = process.argv[2];
let problems = 0;
function check(element) {
const expression = String(toValue(element));
const { result } = parseRuntimeExpression(expression);
if (result.success) return;
const where = `${file}:${element.startLine + 1}:${element.startCharacter + 1}`;
console.log(`${where} invalid runtime expression\n ${expression}\n ${' '.repeat(result.maxMatched)}^ does not parse from here\n`);
problems += 1;
}
Walk the outputs
And finally the document itself. parseArazzo throws a ParseError for a file that is not Arazzo or cannot be read. The script then exits with 2, so a broken file is never mistaken for a clean one.
let parseResult;
try {
parseResult = await parseArazzo(file, { parse: { parserOpts: { sourceMap: true, strict: false } } });
} catch (error) {
if (error instanceof ParseError) {
console.error(error.message);
process.exit(2);
}
throw error;
}
parseResult.api.workflows.forEach((workflow) => {
workflow.steps.forEach((step) => {
step.outputs?.forEach((value) => check(value));
});
});
console.log(`${problems || 'no'} problem${problems === 1 ? '' : 's'}`);
process.exit(problems > 0 ? 1 : 0);
Notice how the typed tree reads like the document: workflow.steps, then step.outputs. Lists and maps have forEach, a map’s callback gets the value first, and a step without outputs has no such field, hence the ?..
Run the script
The complete script is check-expressions.mjs, thirty-four lines. Run it against the sample:
node check-expressions.mjs adopt-a-pet.arazzo.yaml
adopt-a-pet.arazzo.yaml:30:17 invalid runtime expression
$response.body#name
^ does not parse from here
1 problem
Line 30 is the one from the listing at the top of the page, and the column is where the expression starts. The exit status, echo $?, is 1. Fix it, #/name, and run the script again:
no problems
The exit status is now 0. So the script is something to put in front of a run, in a pre-commit hook or a CI job.
Where parsing ends
One more thing before we finish. A valid expression is not automatically one that belongs where it sits.
Look at line 36. The adopt step passes $response.body#/id as a parameter. Paste it into the playground at the top and it parses: it is a well-formed ResponseExpression. And it is still wrong. A parameter is read before the request is sent, so at that moment there is no response. What its author meant was the pet found by the previous step, $steps.find-pet.outputs.petId.
So why can’t the parser catch it? Because the parser told us everything it can. The string is well formed, and it reads from a response. Whether a response expression belongs in a parameter is a rule about the document, not about the string. The same goes for whether find-pet is a step in this workflow, whether petId is one of its outputs, and whether getPetById is an operation in the petstore description.
Those questions need the whole document and the descriptions it names. They are Arazzo document validation, and they are what the Validator is for. Parsing comes first, because it needs nothing but the string.
Next steps
- The script looks at step
outputsonly. A real document holds runtime expressions in many more places, on their own or embedded in a longer string with{}, a request body’spayloadabove all. The full list is in the FAQ below, under “Where can runtime expressions appear in an Arazzo document?” - The runtime expression section of the reference lists the options and the two errors
parseRuntimeExpressioncan throw, neither of which is invalid syntax. - When an expression fails somewhere you did not expect, pass
{ trace: true }toparseRuntimeExpression. The result then carries atrace, andtrace.displayTrace()is a line-by-line account of every rule the grammar tried. - The positions the report uses are on every element of the typed tree, not only the expressions, along with end positions and offsets. See Source maps in the parser reference.
- Something did not work as described? Say so in Discussions.
